High Performance Flat Head Wax

For general purpose labelling with extra durability. Check out our RUB TEST video to see for yourself!

  • Overview
  • Performance
  • Certification
  • Downloads

This high performance resin enhanced wax ribbon is the ideal choice for a wide range of applications, ranging from uncoated paper to synthetic labels. The special ink formulation and unique back coating ensure an excellent antistatic ribbon, ideal for printing RFID labels and extending printhead life.

With print speeds of up to 12 inches per second, it provides dark, durable images with crisp rotated barcodes, text and graphics. SEE FOR YOURSELF HOW IT PERFORMS IN OUR RUB TEST VIDEO HERE…

It has the additional benefits of flexibility and durability, allowing slot-in replacement for other premium wax products without printer setting adjustments. This wax also has the additional advantage of being ISEGA approved for use when the printed image comes into contact with non-fatty foodstuffs. It is available from stock in a wide range of sizes suitable for use on all flat head technology printers.

Performance Characteristics

• Prints on a wide range of substrates from uncoated papers to mid-range synthetic films
• Prints at high speeds (12 IPS)
• Dark, dense images for improved scan rates
• Crisp, rotated barcodes
• Dissipates static – ideal for RFID labels
• Enhanced smudge and scratch resistance
• Superior print quality on flood-coated labels
• Easy to use slot-in replacement for other wax grades
• Printed image on paper substrate can withstand freezing temperatures of up to -26°C

Recommended Substrates

Vellum, uncoated papers, semi-gloss & full gloss papers, tag board, synthetic paper, polyethylene, polypropylene, flood-coated paper, UV varnished labels

*please see datasheet within the download section for full list of certifications and approvals.

Available Products

No Suitable Products Available; Contact us to discuss production in custom sizes
Product CodeWidthLengthWindingCoreCore DiaBox QtyMin Order Qty
GPX10-110100H-IW110mm100mInside110mm Wide Card Core, 2 notches each end13mm2525
GPX10-040360-IW40mm360mInsideStandard Card Core25.5mm3030
GPX10-050360-IW50mm360mInsideStandard Card Core25.5mm3030
GPX10-055360-IW55mm360mInsideStandard Card Core25.5mm3030
GPX10-065360-IW65mm360mInsideStandard Card Core25.5mm1515
GPX10-076360-IW76mm360mInsideStandard Card Core25.5mm1515
GPX10-083360-IW83mm360mInsideStandard Card Core25.5mm1515
GPX10-090360-IW90mm360mInsideStandard Card Core25.5mm1515
GPX10-104360-IW104mm360mInsideStandard Card Core25.5mm1515
GPX10-110360-IW110mm360mInsideStandard Card Core25.5mm1515
GPX10-114360-IW114mm360mInsideStandard Card Core25.5mm1515
GPX10-130360-IW130mm360mInsideStandard Card Core25.5mm1515
GPX10-155360-IW155mm360mInsideStandard Card Core25.5mm1515
GPX10-050450-IW50mm450mInsideStandard Card Core25.5mm2424
GPX10-055450-IW55mm450mInsideStandard Card Core25.5mm2424
GPX10-060450-IW60mm450mInsideStandard Card Core25.5mm1212
GPX10-065450-IW65mm450mInsideStandard Card Core25.5mm1212
GPX10-070450-IW70mm450mInsideStandard Card Core25.5mm1212
GPX10-076450-IW76mm450mInsideStandard Card Core25.5mm1212
GPX10-083450-IW83mm450mInsideStandard Card Core25.5mm1212
GPX10-090450-IW90mm450mInsideStandard Card Core25.5mm1212
GPX10-104450-IW104mm450mInsideStandard Card Core25.5mm1212
GPX10-110450-IW110mm450mInsideStandard Card Core25.5mm1212
GPX10-130450-IW130mm450mInsideStandard Card Core25.5mm1212
GPX10-155450-IW155mm450mInsideStandard Card Core25.5mm1212
GPX10-165450-IW165mm450mInsideStandard Card Core25.5mm1212
GPX10-170450-IW170mm450mInsideStandard Card Core25.5mm1212
GPX10-216450-IW216mm450mInsideStandard Card Core25.5mm1212
GPX10-058074H-OW58mm74mOutside58mm Wide Card Core, 2 notches each end13mm25450
GPX10-064074H-OW64mm74mOutside110mm Wide Card Core, 2 notches each end13mm2525
GPX10-084074H-OW84mm74mOutside110mm Wide Card Core, 2 notches each end13mm2525
GPX10-110074H-OW110mm74mOutside110mm Wide Card Core, 2 notches each end13mm2525
GPX10-110091H-OW 110mm91mOutside110mm Wide Card Core, 2 notches each end13mm2525
GPX10-104155-OW104mm155mOutsideStandard Card Core25.5mm2828
GPX10-170155-OW170mm155mOutsideStandard Card Core25.5mm2828
GPX10-050300-OW50mm300mOutsideStandard Card Core25.5mm3030
GPX10-055300-OW55mm300mOutsideStandard Card Core25.5mm3030
GPX10-060300-OW60mm300mOutsideStandard Card Core25.5mm1515
GPX10-065300-OW65mm300mOutsideStandard Card Core25.5mm1515
GPX10-070300-OW70mm300mOutsideStandard Card Core25.5mm1515
GPX10-080300-OW80mm300mOutsideStandard Card Core25.5mm1515
GPX10-090300-OW90mm300mOutsideStandard Card Core25.5mm1515
GPX10-104300-OW104mm300mOutsideStandard Card Core25.5mm1515
GPX10-110300-OW110mm300mOutsideStandard Card Core25.5mm1515
GPX10-130300-OW130mm300mOutsideStandard Card Core25.5mm1515
GPX10-155300-OW155mm300mOutsideStandard Card Core25.5mm1515
GPX10-170300-OW170mm300mOutsideStandard Card Core25.5mm1515
GPX10-220300-OW220mm300mOutsideStandard Card Core25.5mm1515
GPX10-040450-OW40mm450mOutsideStandard Card Core25.5mm2424
GPX10-050450-OW50mm450mOutsideStandard Card Core25.5mm2424
GPX10-055450-OW55mm450mOutsideStandard Card Core25.5mm2424
GPX10-060450-OW60mm450mOutsideStandard Card Core25.5mm1212
GPX10-065450-OW65mm450mOutsideStandard Card Core25.5mm1212
GPX10-070450-OW70mm450mOutsideStandard Card Core25.5mm1212
GPX10-076450-OW76mm450mOutsideStandard Card Core25.5mm1212
GPX10-083450-OW83mm450mOutsideStandard Card Core25.5mm1212
GPX10-090450-OW90mm450mOutsideStandard Card Core25.5mm1212
GPX10-095450-OW95mm450mOutsideStandard Card Core25.5mm1212
GPX10-104450-OW104mm450mOutsideStandard Card Core25.5mm1212
GPX10-110450-OW110mm450mOutsideStandard Card Core25.5mm1212
GPX10-130450-OW130mm450mOutsideStandard Card Core25.5mm1212
GPX10-140450-OW140mm450mOutsideStandard Card Core25.5mm1212
GPX10-152450-OW152mm450mOutsideStandard Card Core25.5mm1212
GPX10-155450-OW155mm450mOutsideStandard Card Core25.5mm1212
GPX10-165450-OW165mm450mOutsideStandard Card Core25.5mm1212
GPX10-170450-OW170mm450mOutsideStandard Card Core25.5mm1212
GPX10-174450-OW174mm450mOutsideStandard Card Core25.5mm1212
GPX10-220450-OW220mm450mOutsideStandard Card Core25.5mm1212
GPX10-040600-OW40mm600mOutsideStandard Card Core25.5mm2020
GPX10-055600-OW55mm600mOutsideStandard Card Core25.5mm2020
GPX10-060600-OW60mm600mOutsideStandard Card Core25.5mm1010
GPX10-083600-OW83mm600mOutsideStandard Card Core25.5mm1010
GPX10-110600-OW110mm600mOutsideStandard Card Core25.5mm1010
GPX10-130600-OW130mm600mOutsideStandard Card Core25.5mm1010
GPX10-160600-OW160mm600mOutsideStandard Card Core25.5mm1010
GPX10-060625-OW60mm625mOutsideStandard Card Core25.5mm1010
GPX10-080625-OW80mm625mOutsideStandard Card Core25.5mm1010
GPX10-110625-OW110mm625mOutsideStandard Card Core25.5mm1010
GPX10-171625-OW171mm625mOutsideStandard Card Core25.5mm1010
GPX10-220625-OW220mm625mOutsideStandard Card Core25.5mm1010
GPX10-083300T-OW83mm300mOutside118mm Wide Card Centre Wound Core, 2 notches each end25.5mm1515
GPX10-095300T-OW95mm300mOutside118mm Wide Card Centre Wound Core, 2 notches each end25.5mm1515
GPX10-110300T-OW110mm300mOutside118mm Wide Card Centre Wound Core, 2 notches each end25.5mm1515
GPX10-060450T-OW60mm450mOutside118mm Wide Card Centre Wound Core, 2 notches each end25.5mm1212
GPX10-083450T-OW83mm450mOutside118mm Wide Card Centre Wound Core, 2 notches each end25.5mm1212
GPX10-095450T-OW95mm450mOutside118mm Wide Card Centre Wound Core, 2 notches each end25.5mm1212
GPX10-110450T-OW110mm450mOutside118mm Wide Card Centre Wound Core, 2 notches each end25.5mm1212
GPX10-160300T-OW160mm300mOutside239mm Wide Card Centre Wound Core, 2 notches each end25.5mm1515
GPX10-220300T-OW220mm300mOutside239mm Wide Card Centre Wound Core, 2 notches each end25.5mm1515
